3.35MWh Liquid Cooling Container ESS

Model: HY-3.35Mwh
Cell Type: 3.2V/280Ah, LFP (Lithium Iron Phosphate)
Rated Battery Capacity: 3.345MWh
Rated Battery Voltage: 1331.2V
Battery Voltage Range: 1040~1497.6V
Dimensions: 2600*2896*6500 mm
Charge/Discharge Ratio: ≤0.5C
Weight: 32 tons
Protection Grade: IP54
Anti-corrosion Grade: C3/C4/C5 (optional)
Operating Temperature Range: -20~50°C (Ultra-low temperature optional)
Humidity Range: 0~95% (non-condensing)
Cooling Method: Liquid cooling
Fire-fighting Method: Aerosol/Perfluorohexanone (optional)
Communication Method: RS485, Ethernet
System Efficiency: ≥85%

Quantity:
Availability:





Inquire Add to Basket

Model:
HY-3.35Mwh
Brand:
HY Tech
Code:
HY-3.35Mwh

3.35MWh Liquid Cooling Container Container ESS Industrial and commercial energy storage

Introduction

Efficient integration

Highly integrated battery system, AC system, temperature control system, fire control system, etc
High precision intelligence

Smart grid design
Peak cutting and valley filling

Outdoor IP55 design
High efficiency

Intelligent temperature control system
Two-way converter

Product Video

Equipped with high energy density battery, achieving 20GP power of 5MWh

The compact design of a 20ft container provides a more efficient source-grid solution. Aiming at the key technical requirements of the "generation, transmission, distribution and use" of the power system, the HY-C-L5.0 liquid-cooled energy storage system is created to provide full-scenario application solutions for global power users with more advanced technology and better services.
